Flying Probe Technology - Automated Diagnostic Platforms
Huntron Access Probers
A Huntron Access Prober is used to automate the testing of printed circuits assemblies (PCA) that would otherwise have to be tested by
hand. Adding Flying Probe technology your test procedure will
significantly decrease test times therefore increasing productivity.
Access Probers are designed to accurately access test points on PCAs. The exceptional accuracy
achieved by micro-stepping and linear encoding ensures reliable probing of the smallest
surface mounted components. By using either the standard built-in test probe or a custom test
probe, the Huntron Access Probers add flying probe technology to your new or existing equipment.
The high-resolution color camera ensures correct probe placement and provides a
clear view of the PCA under test.
Access Prober Image Gallery -- Click the left/right arrow buttons or select a thumbnail image to step through the Gallery.
Access Prober
Access 2 Prober
Access 2 Probing area
Access Prober in use
Access Prober and board holder
Access DH (dual head) Prober
Access DH Prober Z heads
Access DH Z head Back panel
Access DH - Close-up of standard probes
Automate Test Processes that are Difficult to Perform by Hand
Huntron Access Probers allow for
economical, automated testing of densely packed surface-mount and other devices on the most complex boards from the smallest to the largest systems.
The precision robotic movement lets you probe points on the newest exotic chips, such as PLCCs, SOICs, PGAs, SSOPs, QFPs and others, without any
expensive fixturing or programming required.
Highlights
- Select from single or dual head models
- Exceptional accuracy for precise probing of PCAs
- Durable design for many years of service
- All models can be configured with a Huntron Tracker® Model 30 inside
- Automate tests using other mainline test instruments with optional SDK packages
Choose the Prober Type That Meets Your Needs
Huntron currently manufactures three Access Prober platforms, the standard size single head Access Prober, the larger single head Access 2 Prober and the dual head Access DH Prober.
Huntron Access Probers - (left to right - images not to scale) Access Prober, Access 2 Prober, Access DH ProberAccess and Access 2 Flying Probe
These single head Probers are best suited for low volume testing where a single test probe to the PCA under test is sufficient. The Access and Access 2 Probers have a lower profile and
can be placed on most standard size test benches. They can easily be connected to a Tracker Model 30, TrackerPXI or Huntron ProTrack.
You can also order the Access or Access 2 Prober with the Tracker Model 30 built-in for an all-in-one test solution (the Access DH includes the Tracker Model 30 inside).
You can also develop your own custom Access or Access 2 test platform that connect to other mainline test instruments
using Huntron Software Development Kits (SDK).
Access DH Flying Probe
The Access DH Prober is a dual head Robotic Prober that is best suited for low volume PCA testing where interfacing between two points is necessary. The Access DH stands in it's own cabinet with plenty of space underneath for a rack mounted PC and other test instrumentation. The open architecture design of the Access DH makes it possible for you to utilize many different test technologies where automated probing of the PCA under test makes sense.
Specifications- Huntron Access Probers
| Maximum Board-Under-Test Size | |
| Access USB Prober Access USB Prober 2 Access DH |
19.4" x 14" (49.3cm x 35.6cm) 22" x 23" (56cm x 58cm) 12" x 19" (30.5cm x 48.3cm) |
| Maximum Board-Probing Area | |
| Access USB Prober Access USB Prober 2 Access DH |
15.3" x 12.9 " (38.9cm x 33.8cm) 18.2" x 22.4" (46.2cm x 56.9cm) 12" x 19" (30.5cm x 48.3cm) |
| Maximum Allowable Component Height on Board Under Test | |
| Access USB Prober Access USB Prober 2 |
2.375" (6cm) 4" (10cm) |
| Prober Dimensions | |
| Access USB Prober Access USB Prober 2 Access DH |
26.5" W x 13" H x 24.5" D (67.31cm W x 33.02cm H x 62.3cm D) 36" W x 15.7" H x 29" D (91.44cm W x 39.88cm H x 73.66cm D) 39" W x 61" H x 53" D (99.1cm W x 154.9cm H x 134.5cm D) |
| Accuracy | 0.0007874" (±20 microns); For Access DH this applies to the Top Slot (6" above plate) |
| Minimum Resolution |
0.0003937" (10 microns); Access DH - 0.00002" (0.4 microns) |
| Maximum Z Travel | |
| Access USB Prober Access USB Prober 2 Access DH |
2.21" (5.6cm) 4.2" (10.6cm) 5.5" (14cm) |
| Vision System | Color; 640px x 480px; 1024px x 768px (Access DH) |
| Power Requirements | |
| Line Voltage Power |
115VAC or 230VAC 100W |
| GENERAL | |
| PC Interfaces | USB |
| Certifications | CE and ETL listed |
| Warranty | 1 year limited |
Supplied Accessories with Probers
| Huntron P/N | Qty | Description | Available Online? |
| All Probers | |||
| 06-5217 | 1 | Manuals CD | Buy Now! |
| 98-0043 | 4 | Common Test Lead | - |
| 98-0126 | 1 | Spring Probe Kit | Buy Now! |
| 98-0227 | 1 | Common Lead with Ferrite Bead (EMI reduction) | - |
| 98-0418 | 1 | USB Cable | - |
| 98-0452 | 1 | Tool Kit | - |
| 98-0422 | 1 | National Instruments Vison Runtime License | - |
| Access USB Prober | |||
| 98-0393 | 1 | Crossbar Assembly - 19 1/4” | - |
| 98-0132 | 1 | Slide Bar Extension | - |
| 98-0133 | 1 | Extended Slide Bar | - |
| 98-0109 | 1 | Slide Bar Assembly | - |
| 98-0111 | 4 | Board Spacer | - |
| 98-0228 | 1 | 3/32 Allen Wrench for Board Spacers | - |
| 98-0223 | 2 | BNC Cables | - |
| Access 2 USB Prober | |||
| 98-0119 | 1 | Crossbar Assembly - 22” | - |
| 98-0132 | 1 | Slide Bar Extension | - |
| 98-0133 | 1 | Extended Slide Bar | - |
| 98-0109 | 1 | Slide Bar Assembly | - |
| 98-0167 | 1 | PCA Support Kit | - |
| 98-0292 | 4 | Board Spacer (4 slot) | - |
| 98-0228 | 1 | 3/32 Allen Wrench for Board Spacers | - |
| 98-0223 | 2 | BNC Cables | - |
| Access DH Prober | |||
| 98-0579 | 1 | Rotating Board Holder Kit | - |
| 01-3536 | 2 | Access DH Probe Holder (spares) | - |
